Tony Whetstone's

1988 Mustang GT Convertible

Twin-turbo Coyote • Holley EFI • E85 • Powerglide

Twin HPT F3 7880sSleeved Gen 3 Coyote3.55 Gear275/60-15

Current 2026 Combination

The Coyote Build

The old 348 SBF combination had a great run. The car has moved on to a sleeved, twin-turbo Coyote setup built around Holley EFI and E85.

01. Engine & Valvetrain

  • FFRE Gen 3 sleeved Coyote block
  • 3.630 in. bore, Manley forged pistons
  • Manley I-beam connecting rods
  • Approximately 11:1 compression
  • Gen 2 Coyote cylinder heads with Manley valves
  • Comp 1281 valve springs with titanium retainers
  • Gen 2 cams with mechanical lockouts
  • Boundary CM-S1 oil pump

02. Boost & Induction

  • Twin HPT F3 7880 turbos, .96 A/R
  • Twin 44 mm wastegates with CO₂ dome control
  • 1320 Junkies ported Boss 302 intake manifold
  • ICON 92 mm throttle body
  • On3 air-to-air intercooler
  • 3 in. hot-side / 3.5 in. cold-side charge piping
  • 50 mm blow-off valve

03. Fuel, EFI & Ignition

  • E85 fuel
  • Dual Weldon 2345A fuel pumps
  • Weldon pump controller and pressure regulator
  • 210 lb/hr injectors
  • Holley Dominator EFI
  • Holley 6.86 in. digital dash
  • Holley IGN-1A smart coils
  • NGK R7448A-8 spark plugs

04. Drivetrain & Chassis

  • Powerglide, 1.80 / 1.00 gearset
  • Ford 8.8 rear axle with 3.55 gears
  • 33-spline Moser axles and spool
  • UPR K-member, front suspension and rear control arms
  • UPR anti-roll bar
  • Wolfe 10-point roll cage
  • Aerospace front and rear brakes
  • Billet Specialties Street Lite wheels
  • M/T 275/60-15 Street R rear tires

05. Cooling & Plumbing

  • Griffin aluminum radiator
  • Meziere WP337S remote 55 GPM electric water pump
  • BPS front coolant adapters
  • UPR rear cylinder-head cooling mod
  • -12 / -16 AN cooling-system plumbing
  • Holley pressure and temperature monitoring

06. Wheels & Appearance

  • Bright Atlantic Blue exterior
  • 1993 Cobra-style rear valance
  • Billet Specialties Street Lite 15x3.5 front wheels
  • Billet Specialties Street Lite 15x10 rear wheels
  • M/T ET Front tires
  • M/T 275/60-15 Street R rear tires

Track History

Numbers That Matter

The quickest passes below are part of the car's history; the new twin-turbo Coyote combination is the next chapter.

7.92Previous SBF 1/4-mile best177 MPH • 1.20 60-ft
5.04Previous SBF 1/8-mile best144 MPH
2,000+Coyote power goalRWHP target — not a claimed dyno result

From Windsor to Coyote

A long way from the original mod list.

This page originally documented the car with a 348 cubic-inch Boss-block small-block Ford, Twisted Wedge heads, a single S480 and FAST XFI. That combination eventually pushed the convertible into the 7s at over 175 MPH.

The current direction is a sleeved Gen 3 Coyote short block with Gen 2 heads, twin 78 mm turbos, Holley Dominator EFI and E85. The drivetrain is now centered around a Powerglide, while the car keeps the same Fox-body roots, 8.8 rear axle and drag-oriented UPR/Wolfe chassis setup.

During the Coyote program the car has also run a stock Gen 1 F-150 Coyote combination, including a 9.72 @ 139.30 MPH quarter-mile pass.

The Archive

Photos & Video

I kept the old photo archive intact instead of throwing away twenty-plus years of the car's history.

1999200320042006200920102012Misc Gallery
